Samsung Electronics launched its ‘Flashbolt’ third-generation High Bandwidth Memory 2E (HBM2E). The new 16-gigabyte (GB) HBM2E is targeted at high performance computing (HPC) systems and help system manufacturers to advance their supercomputers, AI-driven data analytics and state-of-the-art graphics systems in a timely manner.
The 16GB capacity is achieved by vertically stacking eight layers of 10nm-class (1y) 16-gigabit (Gb) DRAM dies on top of a buffer chip. This HBM2E package is then interconnected in a precise arrangement of more than 40,000 ‘through silicon via’ (TSV) microbumps, with each 16Gb die containing over 5,600 of these microscopic holes.
The data transfer speed is 3.2 Gbps by leveraging a proprietary optimized circuit design for signal transmission, while offering a memory bandwidth of 410GB/s per stack. Samsung’s HBM2E can also attain a transfer speed of 4.2Gbps, the maximum tested data rate to date, enabling up to a 538GB/s bandwidth per stack in certain future applications. This would represent a 1.75x enhancement over Aquabolt’s 307GB/s.
“With the introduction of the highest performing DRAM available today, we are taking a critical step to enhance our role as the leading innovator in the fast-growing premium memory market,” said Cheol Choi, executive vice president of Memory Sales & Marketing at Samsung Electronics. “Samsung will continue to deliver on its commitment to bring truly differentiated solutions as we reinforce our edge in the global memory marketplace.”
